All-in-One Series · Home Energy Storage

ESS-6200W-5kWh

5kWh All-in-One Solar Storage System

Grid-tied operation with 6200W inverter output. Floor-standing all-in-one design with an IP41 enclosure rating for residential energy storage installations.

Rated Output: 6200W
Battery Capacity: 5120Wh
Operating Mode: Grid-Tied
Cycle Life: 8000 Cycles

Key features

Integrated Residential Energy Storage

The all-in-one series combines battery storage, inverter output and PV input in one floor-standing system.

LiFePO4 Battery

Integrated lithium iron phosphate battery storage matched to the selected system capacity.

6200W Inverter Output

Rated inverter output of 6200W across the current residential ESS series.

PV MPPT Input

High-voltage PV input with MPPT operating range defined in the model specifications.

All-in-One Architecture

Battery, power electronics and system controls are integrated into one enclosure.

System flow

How the System Connects

Grid-tied model for residential solar self-consumption applications.

Solar PVDC generation

MPPT InputPV conversion

All-in-One ESSESS-6200W-5kWh

Home LoadsAC supply

Operating mode: Grid-Tied

Full specification

Technical Specifications

Battery Specifications

Battery Type: LiFePO4 3.2V / 100Ah
Battery Voltage Range: 40V–60V
Max Charging Current: 100A
Max Output Current: 100A
Rated Charging Power: 4000W
Rated Discharging Power: 6200W
Battery Capacity: 5120Wh

PV Input

Max Input Power: 6000W
Start-up Voltage: 120V
MPPT Operating Voltage Range: 120–450V
Max Input Voltage: 500V
Single MPPT Input Current: 20A
Single MPPT Max Input Current: 22A
MPPT Input Channels: 1

AC Output — Grid-Tied

Rated Output Power: 6200W
Max Output Power: 6200W
Rated Output Voltage: 220V / 230V
Output Voltage Range: 180–270V
Rated Frequency: 50 / 60Hz
Max Output Current: 27A
Transfer Time: 10ms
Power Factor: 0.8 leading ~ 0.8 lagging

Mechanical Specifications

Dimensions: 550 × 280 × 807mm
Operating Temperature: -15°C ~ 55°C
Enclosure Rating: IP41
Battery Life: 8000 Cycles, 0.5C, 90% DOD (25°C)
